PII03400AR39A
PIISUN
| Quantity: | |
|---|---|
| Size | 3.4 inch |
| Model No | PII03400AR39A |
| Resolution | 800*800 |
| AA(mm) | 87.6*87.6 |
| Brightness | 350 nit |
| PIN | 39 |
| Interface | MIPI |
| Viewing angle | All |
| Display mode | Transmissive |
| IC | ILI9881C |
| Touch Screen | Resistive and capacitive touch panel |
| Work Temp | -20~70°C |
| Storage Temp | -30~80°C |
The IPS transmissive type color active matrix TFT liquid crystal display. In-Plane Switching (IPS) was one of the first refinements to produce significant gains in the light-transmissive characteristics of TFT panels. It is a technology that addresses the two main issues of a standard twisted nematic (TN) TFT display: color and viewing angle.
MIPI Mobile Industry Processor Interface is a relatively new standard, mainly used in mobile device applications. The application can be divided into DSI (display bus interface) serial display interface, CSI (camera serial interface), DPI (display pixel interface). DSI defines a high-speed serial interface between the main processor and the display module. The MIPI TFT LCD module introduced by Raystar has a high-speed advantage compared to the RGB interface. Our MIPI DSI standard TFT LCD display module contains
different features, including high brightness, wide temperature, and wide viewing angle, etc.
