Standards: USB V1.1, 1.0, 2.0, 3.1, RS-485/RS-422 EIA ● USB signal: VCC, DATA+, DATA-, GND, FG ● RS-485 signal: T/R+, T/R-, GND ● RS-422 signal: T/R+, T/R-, RXD+, RXD-, GND
Working mode: Asynchronous, point to point or point to multi-point, 2-wire half duplex, 4-wire full duplex ● Direction control: Adopts flow direction auto-control technology, auto identify and control the flow transmission direction ● Baud rate: 300-921,600bps
Load capcity: Supports point to multi-point, allows to connect up to 32 sets RS-422 or RS-485 device ● Transmission distance: RS-485/422 1,200m(9600bps), USB no more than 5m ●Port protection: 600W surge, ±15KV ESD protection ● Connector: USB-C male, DB9 male ● Signal: TXD, RXD
Transmission media: Twisted-pair or shielded wire ● Baud rate: 921,600bps 300M 38,400bps 600M 9,600bps 1.2KM ● Dimension: 55mmX36mmX18mm
Working temperature: -40℃ to 85℃ ● Relative humidity: 5% to 95% ● Supports Win2000/2003/2008/2012/XP/Vista/7/8/8.1/10/CE/Mac/Linux
